ToneFreq's Daily Pedal: Seymour Duncan SFX-08 Power Grid distortion

The Seymour Duncan SFX-08 Power Grid distortion pedal gives you the overdrive and distortion you want, the control you need, and the power you crave! The SFX-08 Power Grid includes five stages of Class A discrete circuitry, cascaded to give you almost 100dB of gain. It's contained by a comprehensive gain and volume control system, allowing you to dial in an array of impressive OD and distortion tones. An onboard 3-band EQ gives you even more tweaking options, whith 12dB of boost or cut on each band. Put the power of amazing crunch tones at your command with the SFX-08 Power Grid!

Seymour Duncan SFX-08 Power Grid Distortion Pedal Features:
Gain range: 0-97dB
Input impedance: 100KOhm
Output impedance: 25KOhm
Max output before saturation: 2.6Vrms
S/N ratio: 120dB referred to the input with 20KOhm source impedance
THD @ 1Vrms out @ 1KHz with 60dB of gain: 0.12%
Type of circuitry: Discrete, Class A Bi-polar transistor
Power: DC 9 - 12V; battery or regulated DC adapter
Current consumption: 4.5 mA Max
Dimensions: 5.50" W x 5.20" D x 2.20" H
Weight: 1.9 lbs
Chassis material: 16 gauge steel

Street Price $99.95
